Skimmer 17″ Flush Mount
Product Description
Last inventory update: June 30, 2024 12:05 pm
Resources
General Product Information
Product Dimensions
Lamping Specifications
LED Information (LED Only)
Pipe / Chain / Cord Information
Additional Information
General Product Information
| Parent Code | DVP37842 |
| Family | Skimmer |
| Product Class | Ceiling |
| Product Subclass | Flush Mount |
| Room Category | Living Spaces |
| Warranty | 5 Years Residential or 20,000 Hours Commercial |
Product Dimensions
| Product Length / Diameter | 17 inches | 431.8 mm |
| Product Width | N/A inches | N/A mm |
| Product Depth | N/A inches | N/A mm |
| Product Height | 2.5 inches | 66.5 mm |
| Minimum Product Height | 2.5 inches | 66.5 mm |
| Maximum Product Height | N/A inches | N/A mm |
| Canopy Length / Diameter | 17 inches | 431.8 mm |
| Canopy Width | N/A inches | N/A mm |
| Canopy Thickness | 0.75 inches | 16 mm |
Lamping Specifications
| Orientation of Light Source | Down |
| Number of Sockets | 1 |
| Total Wattage | 20 |
| Wattage of Individual Bulb Socket | 20 |
| Voltage (V) | 120 |
| Lamping Confinement | Fully Enclosed |
| Socket Type | AC LED |
| Recommended Bulb | N/A |
| Bulbs Included | No |
LED Information (LED Only)
| Initial Lumens Output | 1350 |
| Delivered Lumens (2700K) | N/A |
| Delivered Lumens (3000K) | 784 |
| Delivered Lumens (3500K) | N/A |
| Delivered Lumens (4000K) | 809 |
| Delivered Lumens (5000K) | 803 |
| Required Dimmer | C•L / LED+ / Universal LED |
| CRI | 80+ |
| Color Temperature | 3000K / 4000K / 5000K |
Pipe / Chain / Cord Information
| Pipe / Chain Included | Not Included |
| Pipe Information | N/A |
| Chain Information | N/A |
| Wire / Cord Information | 8 in |
| Max Sloped Ceiling Angle | N/A |
| *Conversion 19° to 45° : ASY0101 + Finish (2 Loops + 1 Chain): For Additional Cost | |
Additional Information
| Wall / Ceiling Mountable | Yes |
| Up / Down Mountable | No |
| Installation Height Adjustable | No |
| Location Certification | Dry Locations Only |
| ADA Compliant | No |
| Heavy Duty Mounting Kit Available | No |
| Additional Kit Available | No |
